48 v phantom power for up to two condenser microphones.
The Neumann N 248 supplies one stereo microphone or two mono condenser microphones with 48 V phantom power (P48). All connectors are of XLR 3 type. The audio signal outputs are DC-free and the five directional patterns of the TLM 170 R can be remote controlled with rotary switches. The remote control operates by varying the nominal phantom voltage of 48 V over a range of ± 3 V (patented). As in standard operation, cable lengths up to 300 m are permissible. Set to P48, all conventional microphones can be used as well. Even mixed operation is possible, with one channel remote controlling a TLM 170 R and the second output supplying a conventional microphone.
Specifications
- DC voltage input: 5 - 15 V
- Power consumption: max. 3 VA
- DC voltage output: 48 V +/- 3 V each
- Current output: max. 5 mA each
