In-Ear monitoring system with dual inputs for each receiver.
The AS-1800-2 Wireless In-Ear Monitor Twin Pack System from Galaxy Audio gets your sound from the board to four performers synchronously connected on stage. This AS-1800-4 Band Pack system consists of one AS-1800T transmitter along with four AS-1800R belt-pack receivers and four sets of EB4 ear buds. This quality IEM system has been designed for working musicians of all types. Also, a Mixed Mono features allows performers to have their vocals in Input 1 and the band mix in Input 2 with independent volume control over each to create their own personal mix. Alternatively, two different monitor mixes can be sent from the board so each performer can decide which mix they want to hear right from their belt pack.
Specifications
AS-1800 System
- Band: UHF
- Audio Frequency Response: +/-1dB 45Hz - 18kHz
- Operating Temperature: Range 14ºF to 122ºF (-10 Cº to +50 Cº) Note: battery characteristics may limit this range
- Frequency Stability: ±0.0005%, UHF Phase Lock Loop frequency control
- Total Harmonic Distortion: < 0.7% @ 1KHz
- Signal to Noise: >105dB
- Max. Deviation Range: ±68KHz
- Channels:
- B2 538~554 MHz - 32 Channels / 640 Selectable Frequencies
- B3 554~570 MHz - 32 Channels / 640 Selectable Frequencies
- P3 485~517 MHz - 50 Channels / 1280 Selectable Frequencies
Features
AS-1800 System
- Mixed Mono Mode
- Up to 50 Channels and 1280 Selectable Frequencies
- 300 ft. Range
- UHF Phase Locked Loop
- Stereo or Mono Transmission
- Naming Function
- 30/100 mW Selectable Transmitter Output
- Single/Dual Rack Mount Kit Included
- Multiple Receivers can be used with 1 Transmitter
- EB4 Ear Buds Included
- An unlimited number of receivers may be added at any time
