HEDD TYPE 05 MK2 5" Powered Studio Monitor (Each)

  • Item # 1549305
  • Model # Type 05 MK2

Studio engineers requiring powerful, accurate monitoring will be dazzled by the single, black HEDD Audio Type 05 MK2, a compact, precision, nearfield studio monitor well suited for mobile broadcast st… Learn More

$799.00

Reserve Now! This item is backordered but it is available to reserve now. You will not be charged until the item ships.

Ship to Store

2-7 business days

Updated lacquer finish for higher durability and better looks.

Studio engineers requiring powerful, accurate monitoring will be dazzled by the single, black HEDD Audio Type 05 MK2, a compact, precision, nearfield studio monitor well suited for mobile broadcast stations, recording and home studios, multichannel setups, and VoIP conferences.The Type 05 MK2 adds several enhancements including the on-board Lineariser, a phase linearization tool that audibly improved spatial reproduction, as well as port plugs that allow the monitor to go from a bass reflex design to a sealed infinite baffle. The rear panel features a Closed or Ported selection knob, a Low Frequency Extension control, and a Desktop Filter control to dial in your best sound. The 2-way design combines a 5" honeycomb composite woofer and a HEDD Air Motion Transformer (HEDD AMT) tweeter to provide an accurate frequency response of 44 Hz to 40 kHz with a maximum SPL of 112 dB (with two speakers a 1m.)The sturdy unibody casing features an updated lacquer finish for higher durability and better looks. The enclosure ensures that the cabinet remains stable and provides effortless audio, even at full power. The ICE power amplifier offers 100W per driver and is universally powered for compatibility anywhere in the world. The rear panel also features a balanced XLR Input and a digital AES Input and Through, as well as a gain trim and high/low shelf potentiometers.Onboard Lineariser and AestheticsImplemented in the MK2 and subwoofer models is the well-known Lineariser, a phase linearization tool that leads to perfect impulse response and an audibly improved spatial reproduction. The MK2 Monitors have a new and improved lacquer for higher durability and better looks.CoP TechnologyUsers for the first time can choose between the energy and bass capacities of a modern bass-port design, and the painstaking precision and control of a closed cabinet approach. Removable plugs for the bass reflex tubes, together with complimentarily designed filter setups allow optimum results in either mode.Linear Sub-Satellite SystemHEDD Audio introduces a completely phase linear Sat-Sub system. These are the first Satellite Sub systems that are completely right in time by combining a phase-linearized subwoofer (separately sold) with a correspondingly time delayed (group delayed) satellite output. Additionally, the listener can compensate eventual distances between subwoofers and satellites to stay with linear phase reproduction for the complete system. For powered monitors for studio, home recording and more. Order today.

Features

  • No-Compromise Compact Monitor with on-board Lineariser and CoP
  • 2-Way-System with 5” Woofer and High-Resolution HEDD AMT Tweeter
  • Integrated Amplifiers with 2x100W for up to 112 dB SPL/pair
  • Closed-or-Ported Functionality
  • Integrated DSP with AD/DA: 96 kHz, 32 Bit
  • HEDD Lineariser Phase-Correction
  • Adjustable LFE, Shelf and Desk Filters
  • Available early 2021 in Black or White
  • MSRP: 1,300€ / pair incl. 19% VAT

Technical Specification

HEDD TYPE 05 MK2 5" Powered Studio Monitor (Each)

Woofer (honeycomb diagram)

  • 5’’ (1.5’’ voice coil)

Midrange (honeycomb design)

Tweeter

  • HEDD AMT

Crossover frequencies (48 db/oct)

  • 2 500 Hz

Input analog and digital (AES)

  • 2x XLR

Input impedance (balanced)

  • 22 kΩ

Input gain

  • ± 12 dB

Input sensitivity (A/D modulation)

  • -10 /-4 / 0 / +4 dB

Output: AES “through”

  • XLR

HEDD Lineariser®, disengageable, delay

  • 10 ms

Shelve filters high / low (.5 dB steps)

  • ± 4 dB

LF range (-3 dB): normal / extended / satellite

  • 45 / 38 / 80 Hz

Desk filter: small / medium / large

  • 180 Hz (-1 / -2 / -4 dB)

Frequency response (-3 dB)

  • 45 - 40 000 Hz

Maximum SPL (per pair)

  • 112 dB

Power amplifier / universal mains 110 - 240 V

  • 2x 100 W ICEpower

AD/DA Conversion

  • 96 kHz / 24 Bit

Cabinet with satin lacquer finish

  • black or white

Dimensions

  • (H x W x D) 308 x 180 x 245 mm

Weight

  • 6.4 kg

Warranty

  • 2 years
