DPA Microphones 4088 CORE Directional Headset Microphone for Wireless with 3-pin LEMO Connection (Small)

  • Item # 1566497
  • Model # 4088-DC-A-B03-LH-S

The 4088 CORE Directional Headset Microphone for wireless with 3-pin LEMO connection (small) from DPA Microphones provides excellent off-axis rejection in high-SPL situations and efficiently supp… Learn More

$915.00

Ship to Store

2-7 business days

Relatively prominent bass roll-off in a head-worn cardioid mic.

The 4088 CORE Directional Headset Microphone for wireless with 3-pin LEMO connection (small) from DPA Microphones provides excellent off-axis rejection in high-SPL situations and efficiently suppresses distant sound sources making it ideal for demanding live performance environments where background noise and feedback are concerns. The bass roll-off will be relatively prominent at a greater distance due to the bass response design for optimal linearity at 1 in. from the sound source. Order the 4088 CORE Directional Headset Microphone for Wireless with 3-pin LEMO connection (small) today.

Features

  • Pristine audio quality
  • Lightweight and flexible
  • Easy mounting to the left or right
  • Resistant to humidity
  • Flexible adapter system fits most professional wireless systems

Technical Specification

DPA Microphones 4088 CORE Directional Headset Microphone for Wireless with 3-pin LEMO Connection (Small)

  • Directional pattern: Cardioid
  • Principle of operation: Pressure gradient
  • Cartridge type: Pre-polarized condenser
  • Frequency response: 20 Hz-20 kHz
  • Rated output impedance: 30-40 ohm
  • Cable drive capability: Up to 984 ft. with DAD6001-BC XLR adapter
  • Power supply for wireless systems: Min. 5 V, max. 10 V through DPA adapter
  • Current consumption: Typ. 1.5 mA (microphone), 3.5 mA with DAD6001-BC XLR adapter
  • Connector: MicroDot, TA4F Mini-XLR, 3-pin LEMO, Mini-Jack
  • Weight: 0.03 lb. including cable and MicroDot connector
  • Microphone diameter: 0.21 in.
  • Microphone length: 0.5 in
  • Cable length: 3.9 ft
  • Cable diameter: 0.06 in.
  • Polarity: Positively increasing sound pressure produces positive going voltage on MicroDot pin
